اللون
- أبيض
الكاميرا
Image Sensor | 1/3” Progressive Scan CMOS Starlight Sensor |
---|---|
Lens | Focal Length: 3.2 mm Aperture: F1.6 Field of View: 112° (Diagonal), 95°(Horizontal), 53°(Vertical) |
Motion Range | Pan Mechanical Range: 340° (360° Pan Coverage) Tilt Mechanical Range: 60° (130° Tilt Coverage) |
Night Vision | 850 nm IR LED (98 ft / 29.9 m) Full-Color Night Vision |
Lighting | 2× Built-in Spotlights |
Interface & Button | 1× Ethernet Port 1× RESET Button 1× MicroSD Card Slot (Up to 512GB) |
الفيديو والصوت
Maximum Resolution | 2K QHD 4MP (2560 × 1440 px) |
---|---|
Frame Rate | 15/20/25/30 fps (Default 15 fps) |
Digital Zoom | 12x |
Video Compression | H.264 |
Live View | Yes |
Image Enhancement | 3DNR WDR |
Audio Input & Output | Built-in Microphone and Speaker |
Audio Communication | Two-Way Audio with Noise Cancellation |
Siren Volume | 93 dB (Level measured at 4-inch/10-cm distance) |
التخزين
Local Storage | MicroSD Card Slot on Camera (Up to 512 GB) General Information about using MicroSD Cards > |
---|---|
Cloud Storage | Tapo Care Cloud Storage Services (Subscription required) |
الكشف والاشعارت
AI Detection | Motion Detection Person Detection Pet Detection Vehicle Detection Line-Crossing Detection Tamper Detection |
---|---|
Activity Zones | Yes |
Output Notification | System Notification System Notification with Snapshot (Tapo Care Services) |
الشبكة
Network Connectivity | Connect via Wi-Fi or Ethernet |
---|---|
Wireless Connectivity | IEEE 802.11b/g/n/ax, 2.4 GHz Wi-Fi |
Ethernet Port | 1× 10/100 Mbps RJ45 Port on Camera |
RTSP | Yes |
ONVIF | Yes |
الامان
Security | On-Device Machine Learning 128-bit AES Encryption with SSL/TLS WPA/WPA2-PSK |
---|
الطاقة
Power Source | 9V DC Power Adapter |
---|---|
Input Voltage | 100-240 V, 50/60 Hz |
Output Voltage | 9 V, 0.85 A (DC Power) |
عام
Smart Integration | Google Assistant, Amazon Alexa |
---|---|
Weather Resistance | IP66 |
System Requirements | Tapo App: iOS 9.0 or higher, Andriod 4.4 or higher |
Mounting Options | Ceiling-Mounted Wall-Mounted Pole-Mounted (Pole-Mounting loops required but not included) |
Operating Temperature | -30℃~60℃ |
Storage Temperature | -40℃~60℃ |
Operating Humidity | 10%~90% RH, Non-condensing |
Storage Humidity | 0~90% RH, Non-condensing |
Dimensions ( W x D x H ) | 4.9 × 4.8 × 3.5 in (123.8 × 123 × 90 mm) |
Package Content | Tapo C520WS Camera Power Adapter Mounting Anchors Mounting Screws Bracket Screws Mounting Template Mounting Bracket Waterproof Seal Waterproof Cable Attachments Quick Start Guide |
Certifications | CE, FCC, RoHS, RCM |
* المواصفات السابقة هي قيم نظرية تستند إلى تصميم المنتج. من أجل تقديم معلومات ومواصفات وسمات دقيقة للمنتجات، قد تقوم الشركة المصنعة بإجراء تعديلات لحظية على المواصفات السابقة، حتى تطابق أداء ومواصفات ومؤشرات ومحتويات المنتج الفعلي. تخضع معلومات المنتج إلى التغيير والتعديل دون إخطار.
